Ender 3 : Upgrade to MKS Gen L v1.0 + TMC2208(Legacy) - Part2

Описание: This is the second part of the series of videos on how to replace the stock mainboard on the Ender 3 with the MKS Gen L v1.0 board together with the TMC2208 stepper driver modules operating in legacy/stand-alone mode. This part continues, where the previous left-off, with the detailed step-by-step hardware configuration and set-up. This part ends with a simple demo of the difference in noise levels from the stock mainboard versus this hardware upgrade.

The MKS Gen L v1.0 is based on the RAMPS 1.4 board hence the pinout & labeling are the same. The TMC2208 are high-end stepper drivers which are capable of ultra-quiet operation and detailed configuration via gcode instructions.

Related Videos:
1) Ender 3 : Upgrade to MKS Gen L v1.0 + TMC2208(Legacy) - Part2 --    • Ender 3 : Upgrade to MKS Gen L v1.0 + TMC2...
2) Ender 3 + MKS Gen L : SD Card Add-on Modules & PlatformIO IDE --    • Ender 3 + MKS Gen L : SD Card Add-on Modul...


Hardware:
1) MKS Gen L v1.0 board - https://www.aliexpress.com/item/contr...
2) TMC2208 Stepper Drivers - https://www.aliexpress.com/item/5pcs-...
3) JST XH2.54 3-Pin Housing (End-Stop Connectors) - https://www.aliexpress.com/item/100Se...
4) IDC 10-Pin (LCD Connector) - https://www.aliexpress.com/item/10-pc...
5) Insulated Wire-End Ferrules - https://www.aliexpress.com/item/100pc...


References:
1) MKS Gen L v1.0 Pinout -
2) MKS Gen L v1.0 Wiring - https://ae01.alicdn.com/kf/HTB1FO.QGK...
3) MKS Gen L v1.0 Dimensions - https://ae01.alicdn.com/kf/HTB1YpAqGK...
4) RAMPS 1.4 Pinout - https://reprap.org/mediawiki/images/c...
5) RAMPS 1.4 Schematic - https://reprap.org/mediawiki/images/f...
6) ATMEGA 2560 - https://www.microchip.com/wwwproducts...
7) Creality3D v1.1.2 Stock VREF Values - https://gist.github.com/knoopx/e6c40a...
8) A4988 Datasheet - https://www.allegromicro.com/en/Produ...
9) TMC2208 Datasheet - https://www.trinamic.com/fileadmin/as...


Configured firmware changes -- https://gitlab.com/jugnu-jethi/myende...


Limitations:
1) SD Card slot unavailable on the NEW board
2) Need a mounting bracket if re-use of original mainboard casing is desired.
3) MAY need to replace 2-pin end-stop connectors with 3-pin ones as NEW board has 3-pin sockets.
4) MAY need to replace stock LCD connector as the connection is reversed at mainboard-side.
