Hibbeler's 10th Edition Example 5.1 Torque and Shear Stress of a Solid Shaft vs. a Hollow Tube

Описание: In this video, we solve Hibbeler’s Mechanics of Materials, Example Problem 5.1, comparing the torsional behavior of a solid shaft and a hollow tube subjected to torque.

This example highlights an important engineering insight: removing material from the center of a shaft can dramatically improve efficiency without significantly reducing strength.

We also examine the shear stress distribution and the stress elements that develop in a shaft under torsion.

🔍 What This Example Covers
When a circular shaft is subjected to torque, shear stresses develop throughout the cross section according to the torsion relationship: T = (τJ) / r

In this example we:
• Compare the torque capacity of a solid shaft and a hollow tube
• Calculate the maximum shear stress in each case
• Use the polar moment of inertia (J) for each cross section
• Identify where the maximum shear stress occurs
• Examine the state of stress using stress elements

This comparison shows why hollow shafts are widely used in engineering applications, including:
• Automotive drive shafts
• Aircraft structures
• Bicycle frames
• Industrial machinery

🧠 Key Engineering Insight: For torsion problems:
• Shear stress is zero at the center of the shaft
• Shear stress increases linearly with radius
• Maximum shear stress occurs AT the outer surface
• There is no shear stress or normal stress ON the shaft surface itself

Because the center carries little stress, replacing a solid shaft with a hollow tube can save weight while maintaining strength.

This concept is one of the reasons tubes and hollow shafts are so common in engineering design.

📚 Textbook Reference: Mechanics of Materials, R. C. Hibbeler
