Dual SFP+ 10GbE adapter card installation HP Proliant DL380p G8 server

Описание: Dual SFP+ 10GbE adapter card installation HP Proliant DL380p G8 server

HP Proliant DL380p G8 SFF 25 Bay server
HP NC523SFP QLE3242-HP Dual Port 10GbE PCIe Server Adapter Network Card
Finisar FTLX8571D3BCL SFP+SR/SW 10Gb/s Multimode Fiber Optic Transceiver Module


Ubuntu server

$ lspci

...
05:00.0 Ethernet controller: QLogic Corp. cLOM8214 1/10GbE Controller (rev 54)
05:00.1 Ethernet controller: QLogic Corp. cLOM8214 1/10GbE Controller (rev 54)
...

$ lspci -v

...
05:00.0 Ethernet controller: QLogic Corp. cLOM8214 1/10GbE Controller (rev 54)
Subsystem: Hewlett-Packard Company NC523SFP 10Gb 2-port Server Adapter
Physical Slot: 1
Flags: bus master, fast devsel, latency 0, IRQ 102, NUMA node 0
Memory at f7c00000 (64-bit, non-prefetchable) [size=2M]
Memory at f7bf0000 (64-bit, non-prefetchable) [size=64K]
Expansion ROM at f7700000 [virtual] [disabled] [size=256K]
Capabilities: access denied
Kernel driver in use: qlcnic
Kernel modules: qlcnic

05:00.1 Ethernet controller: QLogic Corp. cLOM8214 1/10GbE Controller (rev 54)
Subsystem: Hewlett-Packard Company NC523SFP 10Gb 2-port Server Adapter
Physical Slot: 1
Flags: bus master, fast devsel, latency 0, IRQ 102, NUMA node 0
Memory at f7800000 (64-bit, non-prefetchable) [size=2M]
Memory at f77f0000 (64-bit, non-prefetchable) [size=64K]
Expansion ROM at f7740000 [virtual] [disabled] [size=256K]
Capabilities: access denied
Kernel driver in use: qlcnic
Kernel modules: qlcnic
...

$ udevadm test-builtin net_id /sys/class/net/ens1f0

Load module index
Parsed configuration file /usr/lib/systemd/network/99-default.link
Parsed configuration file /usr/lib/systemd/network/73-usb-net-by-mac.link
Created link configuration context.
Using default interface naming scheme 'v245'.
ID_NET_NAMING_SCHEME=v245
ID_NET_NAME_PATH=enp5s0f1
ID_NET_NAME_SLOT=ens1f1
Unload module index
Unloaded link configuration context.

$ udevadm test-builtin net_id /sys/class/net/ens1f1

Load module index
Parsed configuration file /usr/lib/systemd/network/99-default.link
Parsed configuration file /usr/lib/systemd/network/73-usb-net-by-mac.link
Created link configuration context.
Using default interface naming scheme 'v245'.
ID_NET_NAMING_SCHEME=v245
ID_NET_NAME_PATH=enp5s0f0
ID_NET_NAME_SLOT=ens1f0
Unload module index
Unloaded link configuration context.

$ cat /proc/net/dev

...
ens1f0: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
...
ens1f1: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
...

$ ifconfig

Will not be visible in this list. Must have a valid
link (fiber installed and active) with a ip-address.

$ ethtool -m ethX

When available this command may give also info about
SFP status. Depends on kernel support however and in
this case not known if driver supports this.
