Making XLR Cables #3 - Quality and Faults (Public)

Описание: In this video I show how to build a simple mic cable with no shrink wrap and discuss some tips and trick to make soldering and testing XLR cables easier and faster.

Part 1 Making XLR Cables-    • Making XLR Cables #1 - Solder a Cable & Ti...
Part 2 Stripping and Shields -    • Making XLR Cables #2 - Tips Stripping and ...
Part 3 Quality and Faults -    • Making XLR Cables #3 - Quality and Faults ...
Part 4 Making a Quad Cable -    • Making Quality XLR Cables #4 - Quad Mic Ca...
Part 5 Soldering Irons -    • Making Quality XLR Cables #5 - Best Solder...
Part 6 Gold or Silver Connectors -    • Gold vs Silver (Nickel) Audio/XLR Connecto...

00:00 Intro
01:09 insulation to solder cup distance
02:58 stray wires and fraying
03:42 excess stripping
04:12 matching wire lengths
05:17 clustered wires in a quad cable
06:14 shrink wrap
07:06 solder blob
07:48 chassis ground connection
12:50 soaking the shield wire in solder
13:55 shrink individual and overall
15:03 strain relief vs strip length
16:27 wiring faults
16:58 outro

The first part of a multi part series on mic cable termination. In this video I describe many of the aspects I will cover in future videos and show how to make an XLR cable
