What Do CAT Ratings Mean?

Описание: There are many different types of meters available for us electricians to use. Multimeters, Amp Clamp meters, Hot Sticks, etc. But what are the different CAT ratings for on these meters? In the latest episode of Electrician U, Dustin discusses what the different CAT ratings are for as well as talk about a few different Multimeters available from Klein Tools.

🤘⚡️EU Learning System⚡️🤘
For Individuals --- https://electricianu.com/learning-sys...
For Businesses --- https://electricianu.com/learning-sys...
-Video courses on every side of the electrical trade (theory, code, safety, wiring, install, troubleshooting, leadership, and more)
-Practice exams for 2017, 2020, 2023 code
-YouTube videos categorized and searchable
-Audio lessons
-Forum
-Business version has admin portal and ability to assign learning to technicians and monitor progress
-Any business size from 2 techs to 2,000!

🎓💡CONTINUING EDUCATION💡🎓
Sign up here --- https://electricianu.com/continuing-e...
-State Approved
-Video Based

✍📝PRACTICE EXAMS📝✍
Get them here --- https://www.electricianu.com/electric...
-2017, 2020, and 2023 NEC versions
-Online Residential Wireman Exam
-Online Journeyman Exam
-Online Master Exam
-300 Question Online Code Cannon (not license specific, all code)
-Take as many times as you want
-All of the above come with printable PDFs

🎤🎧PODCAST🎧🎤
Spotify:
https://open.spotify.com/show/7ldCwdx...
Apple Podcast:
https://podcasts.apple.com/us/podcast...

📱👍SOCIALS👍📱
TikTok -   / electricianu
Instagram -   / electrician_u
Facebook -   / theelectricianu
Reddit -   / electricianu
Rumble - https://rumble.com/c/ElectricianU
Discord -   / discord

🎧🎹Music, Editing, and Videography by Drake Descant and Rob LeBlanc🎹🎧

⚡🔨SPONSOR: KLEIN TOOLS🔨⚡
https://www.kleintools.com/

#electrician #electrical #electricity

Each meter is designed to work on a specific voltage range and have a specific amount of current run thru it. If you choose the wrong meter to work on a different range other than intended, it can cause damage to the meter. Think about electrical services and available fault current. The closer you are to the source (transformer) the more available fault current there is, as there is less impedance to stop it. If the service conductors are short, there is less wire to offer any impedance. Also, on the service conductors, there are no loads yet (motors, devices, etc.) to provide impedance. Meters work in much the same way. Each has a certain amount of impedance built into the meter to be able to have its functions work at a certain range of voltage and or amperage.
So, the CAT rating is simply the voltage/amperage category environment it can be used in. The lower the CAT rating, the lower the voltage/amperage it can be used to test for. Something to keep in mind is that you CAN use a higher CAT rated meter to test in a lower CAT rating environment. So, you could use a CAT 4 rated meter to test in a CAT 2 environment, you just shouldn’t go the other way, or you could risk damage!
CAT 1 meters are the lowest rated meter, with about 30 ohms of impedance and a low voltage range, but these probably won’t be something that you would find readily available, so let’s start with the CAT 2 rated equipment. CAT 2 meters have a bit higher impedance with around 12 ohms and able to handle a bit higher voltage. An example of this is a plug tester that is rated at 300v max. CAT 3 meters are the most common category of meter most electricians have; whether it’s a standard tester, a multimeter, or an amp clamp type of meter. These meters are rated at 600v and has an impedance of about 2 ohms. The lower impedance allows more current to flow thru them and at a higher voltage. These types of meters at this CAT rating should work well for most applications that most of us electricians run into daily. Three phase distribution, lighting panels, and the like are things these meters are made for. CAT 4 meters have roughly the same impedance as CAT 3 (around 2 ohms) but allows you to use them up to 1000v.
Meters can also come with several different options depending on which meter you select. Some have backlit displays (so it’s easier to see the readings), some allow you to HOLD the reading, some are even auto ranging. Amperage testing is another option as is temperature readings.
Always choose a quality meter and TAKE CARE OF IT as your life depends on it. Meters should be kept separate from your other tools (preferably in a good case or bag) and do NOT belong in the bottom of the toolbox or rolling around in your van! Same with the leads of the meter. They should be inspected regularly, batteries should be changed frequently, and always test on a KNOWN source before attempting to use them on what you are attempting to test.
