Box Way CNC Machine - Takumi V11
Автор: Takumi USA
Загружено: 2020-10-23
Просмотров: 6318
Описание:
Takumi V Series Box Way CNC Machines: The Takumi V Series CNC machines are heavy-duty, box way CNC machines that feature belt or geared spindles to provide maximum torque. It's the perfect combination of heavy cutting and high stability. Designed and built for heavy material removal parts production and die/mold industries.
Takumi V11 CNC Machine Specs:
Machine Type: Box Ways CNC Machine
CNC Control: Takumi FANUC© H Control
Travels: 43.3 x 26 x 24 in (1,099 x 660 x 610 mm)
Table Size: 45.2 x 25.6 in / 1,150 x 650 mm
Table Max. Load: 2,425.01 lbs / 1,100 kg
Spindle Speed: 6,000 rpm gear driven spindle with 397 lb ft of torque
Motor Power: 14.6/20 HP (11/15 kW)
Spindle Taper: CAT/BT 50
Magazine Capacity: 24 tools
Rapids: 945 x 945 x 787 in/min (24 x 24 x 20 m/min)
Machine Net Weight: 14,960 lbs / 6,800 kg
*CTS Optional
