Samsung 50 inch H Year Backlight Repair...an oldie but a goodie

Описание: Backlight replacement on a Samsung 50 inch H year LED TV #qcsbuilds #backlightrepair #samsung #howto

Time Stamps

0:00 Intro
1:14 Back Removal
2:32 Unit Overview
2:56 Main Board & Power Supply Removal
5:59 Frame & Wall Mount Removal
8:27 Inside Frame Components...Wi-Fi & Button/IR
8:57 Speaker Removal
9:55 T-conn Board Removal
11:56 Inner Frame Removal
18:57 Glass Cleaning
20:48 LCD Glass Removal
22:12 Subframe Removal
25:58 Diffuser and Filter Layer Removal
27:14 Diffuser Supports and Reflector Removal
29:50 Thank you Shopjimmy!
33:31 LED Strip Removal
37:35 LED Strip Installation
40:21 Reflector Installation
41:28 Diffuser and Filter Layer Installation
42:24 Subframe Installation
44:40 LCD Glass Installation
46:45 Final Glass Cleaning
48:23 Inner Frame Installation
52:19 T-conn Board Installation
55:13 Speaker Installation
56:05 Wall Mount Lug Installation
56:50 Outer Frame Installation
57:38 Power Supply Installation & Test
1:00:15 LED Strip Testing...All Good
1:02:08 Main Board Installation
1:03:25 Power Test
1:04:17 Power Supply Replacement...Thank you Ebay
1:07:05 Power On Self Test
1:09:30 Like, Share, Subscribe....and Thank you for watching!!!
