Dynamic Wireless Charging of Electric Vehicles (EVs) | Prototype Project Working Demo
Автор: Karthik Projects
Загружено: 2021-02-04
Просмотров: 53187
Описание:
Working of wireless battery charging for electric vehicles project.
This is demonstration of wireless battery charger circuit for static and dynamic charging of electric vehicles. This project is used for on road charging of electric vehicles or wireless car charging. Here the wireless power transmitter is fixed below the road or parking lot. It consists of a wireless battery charger circuit with a power transmitting coil and receiving coil. It works using inductive resonance power transmission principle using electromagnetic waves. The receiver is placed under the bottom of the vehicle. When vehicle is on the road, the power is transmitted wireless from transmitting coil to receiving coil. The vehicle battery can be charged wirelessly or in dynamic charging, the vehicle runs directly from the wireless power from the transmitter.
Components of the project:
1) Wireless Power Transmitter
2) Wireless Power Receiver
3) Electric Vehicle / Car
4) Power Supply Adapter
For project related inquires:
WhatsApp : +91 9600023691
