Logic Gates : AND,OR & NOT Gate [ Theory + Practical + Application ] HSC & BSc student
Автор: Mishmash Craft
Загружено: 2020-01-12
Просмотров: 148
Описание:
A logic gate is a building block of a digital circuit. Most logic gates have two inputs and one output and are based on Boolean algebra. At any given moment, every terminal is in one of the two binary conditions false (high) or true (low). False represents 0, and true represents 1. Depending on the type of logic gate being used and the combination of inputs, the binary output will differ. A logic gate can be thought of like a light switch, wherein one position the output is off—0, and in another, it is on—1. Logic gates are commonly used in integrated circuits (IC).
#ANDGate
#ORGate
#NOTGate
Music credit:
Dreambye by BraveLion / bravelion
Free Download / Stream: https://bit.ly/dreambye
Music promoted by Audio Library • Dreambye – BraveLion (No Copyright Music)
