MT-512E 2HP
It features a single relay output, for cooling or heating purposes, combined to a cyclical timer for natural defrost. The natural defrost can be forced or performed through an off refrigeration cycle. It also features a configurable digital filter, which has the aim of simulating an increase of mass in the environment sensor, thus increasing its response time, that is, the sensor response becomes slower. In addition to those features, the MT-512E 2HP has tamper-proof function that blocks the keypad preventing unauthorized users changing its settings, and a control function shutdown that deactivates the controlling outputs turning the instrument into a digital temperature indicator.
Dimensions: 71 x 28 x 71 mm

Parameters of MT-512E 2HP:
00:00 - Intro
03:04 - SEt - SetPoint
04:23 - deFr - Forced Defrost
04:44 - LOC - Functions Lockdown
05:26 - Ctrl - Control Functions Shutdown
06:01 - SEt - SetPoint
06:13 - rEg - Minimum and Maximum Temperature Record
06:39 - CrEg - Erase Max. and Min. Values
06:50 - Proc - Show Current Processes
07:26 - Func - Function Selection
07:30 - F01 - Access code: 123
11:02 - F02 - Desired temperature (SetPoint)
11:19 - F03 - Indication displacement (Offset)
11:45 - F04 e F05 - Minimu and maximum setpoint allowed to the end user
12:18 - F06 - Control differential (hysteresis)
13:06 - F07 - Operating mode
13:17 - F08 - Minimum output time on
13:37 - F09 - Minimum output time off
14:00 - F10 - Cooling time (interval between defrosts)
14:15 - F11 - Defrost time
14:35 - F12 - Initial status when energizing the instrument
14:57 - F13 - Temperature indication locked during defrost
15:10 - F14 - Instrument energization delay
15:36 - F15 - Additional time at the end of the first cycle
15:59 - F16 - Compressor status with the sensor damaged
16:24 - F17 - Compressor time on in case of erro
16:38 - F18 - Compressor time off in case of erro
16:54 - F19 - Digital filter intensity
17:21 - F20 - Time for functions lockdown
17:45 - F21 - Control functions shutdown
