Noctua NH-U12A
SN: NH-U12A U12ACA138669
SPECS
Socket compatibility: Intel LGA1700 (included since Q4 2021, older coolers require NM-i17xx-MP78), LGA1200, LGA1156, LGA1155, LGA1151, LGA1150, LGA2066, LGA2011 & AMD AM4, AM5
Height (without fan): 158 mm
Width (without fan): 125 mm
Depth (without fan): 58 mm
Weight (without fan): 760 g
Height (with fan): 158 mm
Width (with fan): 125 mm
Depth (with fan): 112 mm
Weight (with fan): 1220 g
Material: Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
Max. TDP: up to 350W
Fan compatibility: 120x120x25
Scope of delivery: 2x NF-A12x25 PWM 120mm fan, 2x Low-Noise Adaptor (L.N.A), 4-pin PWM y-cable, SecuFirm2™ mounting system for Intel and AMD, NT-H1 thermal compound, Noctua Metal Case-Badge
Warranty: 6 Years
Fan Specification
Model: Noctua NF-A12x25 PWM
Bearing: SSO2
Max. rotational speed (+/- 10%): 2000 RPM
Max. rotational speed with L.N.A. (+/- 10%): 1700 RPM
Min. rotational speed (PWM, +/-20%): 450 RPM
Max. airflow: 102,1 m³/h
Max. airflow with L.N.A.: 84,5 m³/h
Max. acoustical noise: 22,6 dB(A)
Max. acoustical noise with L.N.A.: 18,8 dB(A)
Voltage range: 12 V
MTTF: up to 150.000 h
