NanoHARD - Going through the entire configuration
Автор: GateMovies
Загружено: 2015-02-24
Просмотров: 21515
Описание:
1. Insert the jumper
2. Connect the battery
3. Wait until the blue LED goes off
4. Pull out the jumper
5. Connect the Programming Button
6 SHORT PRESS --- move to next value
--- LED blinks once - Battery protection disabled
--- LED blinks two times - 7.4V Li-po protection
--- LED blinks three times - 11.1V Li-po protection
--- LED blinks four times - 14.8V Li-po protection
7 PRESS & HOLD --- confirm the selected value and move to Active Brake programming
8 SHORT PRESS --- move to next value
--- LED blinks once slowly and once quickly - Active Brake OFF
--- LED blinks once slowly and twice quickly - Active Brake ON
9 PRESS & HOLD --- confirm the selected value
