Mastering your FT-dx10 with WSJT-x for FT8/FT4

Описание: In this video I'll be showing how to integrate your FT-dx10 with the WSJT-x suite of digital modes, especially FT8 and FT4

Download Links:
WSJT-x: https://wsjt.sourceforge.io/wsjtx.html
Dimension 4: http://www.thinkman.com/dimension4/do...
Yaesu Drivers: https://tinyurl.com/2fwuny8d (Select Files Tab)

Chapters:
01:16 Software and Driver Downloads
04:21 FT-dx10 Radio Settings
10:47 WSJT-x Settings
14:00 Operation Overview and FT8/FT4 Demo

Radio Setup (Rig)

Operation Setting (Preset deselected)
OPERATION Setting/General
232C Rate: 9600
232 Time Out Timer: 100 ms
CAT RATE: 9600bps
CAT TOT: 100 ms
CAT RTS: On

RADIO Setting/MODE PSK/DATA
DATA SHIFT (SSB): 1500 Hz
LCUT FREQ: OFF
HCUT FREQ: OFF
DATA OUT LEVEL: 50
TX BPF SEL: 300-2700Hz
DATA MOD SOURCE: REAR
REAR SELECT: USB
RPORT GAIN: 15
RPTT: DAKY

PRESET (DATA-U MODE)
CAT RTS: ON
CAT RATE: 9600 bps
CAT TOT: 100 ms
LCUT FREQ: OFF
HCUT FREQ: OFF
TX BPF: 300-2700Hz
RPORT GAIN: 15
RPTT: RTS

WSJT-x Settings

General tab
My Call: Your Call
My Grid: Your Grid
IARU Region: ALL
Display (Select)
Blank line between decoding periods
Display distance in miles (unchecked = Kilometers)
Tx messages to Rx Frequency window
Show DXCC, Grid, and worked-before status

Behavior (Select)
Double-click on call sets Tx enable
Calling CQ forces Call 1st
Tx watchdog: 6 minutes
Periodic CW ID Interval: 0

Radio Tab
Rig: Yaesu FTDX-10
Poll Interval: 1s

CAT Control
Serial Port: use enhanced port from device driver verify
Baud Rate: 9600 – or…
Data Bits/Stop Bits/Handshake: Default
PTT Method: CAT
Mode: Data/Pkt
Split Operation: None
Test CAT: Green
Test PTT: Red and radio goes to TX mode

Audio Tab
Soundcard:
Input: Line (USB AUDIO CODEC) (may have a number in front)
Output: Speakers (same as above)


Thanks for viewing. Please remember to Like, Share, and Comment. Also, please consider subscribing to this channel.

73 de Tom, ND3N
