EICR Fault Finding on Sockets - Reverse Polarity & High Resistance - Ring Final Circuit Testing

Описание: During an EICR on a ring final circuit (sometimes called a ring main or socket circuit) Matt discovers high resistance on 2 sockets during the figure of eight test and incorrect polarity when live. Matt finds and corrects the fault before testing the circuit the circuit again.

Note - this is a snap shot of the work carried out and is designed to raise questions and talking point in Matts classroom lessons.

🔵 How to Test a Ring Final Circuit - Ring Main or Socket Circuit - Ring Continuity & Polarity Tests    • How to Test a Ring Final Circuit - Ring Ma...

= 🕐 Time Stamps - Cut to the action 🕕 =

00:00 - Fault finding on a ring final circuit
00:32 - Plug in voltage indicator
01:16 - Safe isolation
02:24 - Connections in the socket outlet
03:22 - Terminations not tight
03:34 - Socket reconnected correctly
06:16 - Line and neutral reverse
07:0 - Testing the repaired socket circuit
08:18 - Testing results
09:00 - That's better
09:26 - Earth fault loop impedance testing (Zs)
11:34 - EICR advice

Videos are training aids for City and Guilds (C and G) and EAL courses Level 1, 2, 3 plus AM2, AM2S and AM2E.
