2020 Yamaha R15 V3 🔥 Special Edition

Описание: [Yamaha Colombia] New 2020 YZF R15 Version 3.0 - Factory Concept / Special Edition / YAMALUBE Livery / Red & White Color

Specifications

Type of motor - 4 Stroke SOHC, liquid cooled, 4 valves
Cylinder layout - 1 Cylinder tilted forward
Cylinder - 155CC
Bore per stroke - 58.0 x 58.7mm
Compression Ratio - 11.6: 1
Max Power - 19.3 HP at 10,000 rpm
Maximum torque - 14.7 Nm at 8500 rpm
Start - Electric
Type of lubrication - Wet sump
Feeding system - fuel injection
Fuel capacity - 11L
Switched on - TCI
Battery capacity - 12V, 5.0 Ah
Drums - YTZ6v
Primary reduction system - Gear
Primary Reduction Ratio - 73/24 = 3,042
Secondary reduction system - Chain
Secondary reduction ratio - 48/14 = 3,429
Clutch type - Multidisc in oil / Spiral spring
Type of transmission - 6-speed constant transmission

Gear ratio -
1st gear ratio - 34/12 (2,833)
2nd transmission ratio - 30/16 (1,875)
Transmission ratio in 3rd - 30/22 (1,364)
Transmission ratio in 4th - 24/21 (1,143)
Transmission ratio in 5th - 22/23 (0.957)
Transmission ratio in 6th - 21/25 (0.840)

Chassis type - Diamond
Inclination - 25 ° 30 ′
Advance - 88mm
Front wheel - 100/80 R17 M / C 52P
Rear wheel - 140/70 R17 M / C 66H
Front brake - Disk
Back brake - Disk
Front suspension type - Telescopic fork
Rear suspension type - Swingarm (By cranks)
Main light - LED
Main light - 12V, 10W x2
Seat height - 815 mm
Distance between axis - 1325 mm
Floor distance - 170 mm
Weight (With oil and full gas tank) - 137 kg

Bike Showcased in Feria de las 2 Ruedas 2019 / Colombia
Yamaha R15 Version 3 BS6 / BSVI
