Reefs RC LCG Transmission Mounting Options

Описание: In this video I'll go over some of the different skid adaptor options we have access to from Reef's RC for their LCG Transmission.

The below link with take to XPT3 LCG Transmissions and 3D Adaptors
https://reefsrc.com/collections/xp-tr...

Some Notes:

a) Vanquish - VFD Skid not Twin
Included Button Head M3X8 - 2 (to mount trans to adaptor)
Button Head M3X16 - 1
Button Head M3X10 - 2

b) Vanquish - VRD Skid
Included Button Head M3X8 - 2 (to mount trans to adaptor)
Button Head M3X20 - 1 or CAP M3X20 - 1
Button Head M3X10 - 2

c) SCX10 - Pro Skid
Included Flat M3X8 - 2 (to mount trans to adaptor)
Flat M3X10 - 2
Flat M3X14 - 2 (with no nut)
Flat M3X16 - 2 (with 2 nuts)

d) SCX10 III - Basecamp Builder Kit Skid
Included Button Head M3X8 - 2 (to mount trans to adaptor)
Flat M3X12 - 2
Spacer M3X1.5 - 2 (for under Trans to give room in case the screws for the adaptor used are longer)

e) Capra Kit - Skid
Included Flat M3X8 - 2 (for both types of adaptors to mount trans to adaptor)
Standard / In-runner Adaptor
Flat M3X12 - 4
Servo Gold Spacers - Use to put in the Hols in the Skid to give the 3D adaptor a little spacing from the skid
Flat Adaptor:
Out-runner Adaptor
Flat M3X8 - 4
Servo Gold Spacer - In case the screw knob breaks off

g) Spare Time Hobbie - Capra Skid
Included Flat M3X8 - 2 (to mount trans to adaptor)
M3X1.5 - 2 Spacer for trans
Out-runner trans adaptor with the screw knobs cut off
Flat M3X14 - 4
M3X2.5 - 3 Spacers for adaptor
M3X1.5 - 1 Spacer for adaptor
Servo Gold Spacers - 4 Use to put in the holes in the Skid to the 3D adaptor a little spacing from the skid

f) GSPEED - White Delrin Skid
Flat M3X14 - 2 (to mount trans to skid)
Use 1 of the existing hole for Trans.
Use template that came with lcg trans to drill 2nd hole 42mm from 1st existing hole. The rear of the trans is 20mm from rear of skid.
Counter sink the hole on the bottom to use a flat screw.
