Unique 313-40 Mitered Door Machine - J & G Machinery, Inc.
Automatic cycle with dowel hole boring for accurate alignment of mitered door corners
Production rate of one frame per minute, 15 seconds per cycle
5" maximum width capacity
1" material thickness capacity
45 degree angle fences
Pneumatic clamping system locks during operation for safe machining of parts
(2) 5 HP Shapers with 1-1/4" diameter spindles
Spindles are counter rotating
(2) 1/3 HP dowel alignment drills
Adjustable stops for dowel drilling
Staggered tables provide unlimited length capacity
Digital position indicator
(2) finger joint cutters (includes backers and carbide inserts)
Dust collection requirements: 1,400 CFM per spindle
Compressed air requirements: 90 PSI (1 CFM)
Machine weight: Approx. 1,000 lbs.
