Trailer Hitch Install: 2021 Honda Pilot Curt 13146

Описание: Trailer Hitch Installation For A 2021 Honda Pilot Curt #13146
Vehicle Demonstration: 2019 Honda Pilot
Vehicle Fitment: 2016-2021 Honda Pilot
2014-2020 Acura MDX

Part#: 13146
Hitch Receiver: 2"
Hitch Class: Class 3
Tow capacity: 6,000 lbs
Tongue Capacity: 900 lbs
WD Capacity: 8,000 lbs

Curt 13146 Class 3 Trailer Hitch Receiver
https://www.miamihitches.com/curt-131...

https://www.miamihitches.com/
We install and sell trailer hitches & wiring,
5th wheel & gooseneck hitch,
brake controllers, hitch bike racks, and more!
Contact us to get a free quote! (786) 563-5875
Great Price & Quality Service Guaranteed
*A South Florida Mobile Hitch Shop
Towing Responsibly Since 2013*

Follow our journey!
Instagram:   / miamihitches
Facebook:   / miamihitches
Google: https://g.page/MiamiHitches/
Twitter:   / miamihitches
All Web Links: https://linktr.ee/MiamiHitches

Videos are provided as a guide only. Refer to manufacturer installation instructions & specs for complete information.

Curt 13146 Installation Instructions PDF
https://assets.curtmfg.com/masterlibr...

⏲TimeStamps⏲
0:00 Introduction
0:33 Step 1. Lower the spare tire
0:59 Step 2. Raise the trailer hitch
2:06 Step 3. Raise the spare tire back
2:25 How To Determine The Rise Or Drop For Your Ball Mount
2:44 Outro

Installation Notes:
Hitch cross tube is concealed.
No drilling required.
Trunk access required for hitch installation.

Tools Needed To Install Curt #13146:
Ratchet
22mm Socket
6" Socket Extension
Torque Wrench
Wire Pipe Brush
Safety Glasses

Overview
The CURT class 3 trailer hitch is the most common type of trailer hitch installed on full-size pickup trucks and SUVs. It is also found on full-size cars, crossover SUVs, minivans and mid-size trucks. That is because the Class 3 packs the punch of a heavyweight hitch while still staying light on its feet. This CURT class 3 hitch offers a gross trailer weight capacity of 6,000 lbs. and a comparable tongue weight capacity of 900 lbs. It is designed to be a custom-fit trailer hitch for certain years of the Acura MDX SUV (to verify your vehicle compatibility, see the CURT application guide at curtmfg.com). It features a square tube frame and comes with all necessary hardware for a complete installation.

The 2" x 2" receiver tube opening of this class 3 hitch is able to accept a hitch-mounted accessory, such as a bike rack or cargo carrier, or a ball mount to tow most standard size trailers, including utility trailers, single-horse livestock trailers, boat trailers, and large campers. One special feature about the class 3 that is not found in classes 1 or 2 is its compatibility with a weight-distribution hitch. When used in combination with a WD hitch, this class 3's gross trailer weight capacity increases to 8,000 lbs. and the tongue weight capacity to 900 lbs. (NOTE: Never exceed the lowest weight capacity of any towing component). CURT class 3 trailer hitches are engineered to be strong and capable, having a quality steel frame and a solid finish. They are put through strenuous testing before being deemed ready for market and come with two coatings -- a liquid Bonderite coating and a powder coat in high-gloss black -- that cure together to form a strong resistance against rust, scratching, UV damage and other wear. Our hitches are our pride, and as such, we back them up with a limited lifetime warranty and a one-year finish warranty.

#TrailerHitchInstall #CurtTrailerHitch #HondaPilot #MiamiHitches #TowResponsibly

---------
