HOW to Use LED VIDEO WALL SOFTWARE | HDPlayer | D10 D20 D30 | led video wall software

Описание: LED VIDEO WALL, VIDEO PART:2
How to easy install HDPlayer.5.3.102.0 Full Color Controller Software in D10/ D20/D30 Controller Card.
The controller can connect to the computer directly. It can also connect to the computer via the Router or WIFI, No need to do network setting. When connected with computer, the network port (The Green light always flicker, then wait for few seconds (Windows XP need more than 50 Seconds, Windows 7 only need 40 Seconds). When the right corner of computer show Network normal (see below), it means it have been connected of network. Plug U-Disk into PC, click (control)- (export to U Disk) or click Export to UDisk on tool bar, choose “Update Program”, programs will be exported into U-Disk. Plug U-Disk into control card, program on U-Disk will be copied to the card’s storage board; screen will come out the tips.
Take away the U-Disk after copy. Screen will display the new program. Repeat same operation when renew program. USB extension cable should be within 5m. Choose “Display” after exporting program to U-Disk. Control card will display contents on U-Disk after inserting U-Disk into card. (No need to restart computer, program will begin display once inserting U-Disk into card). By this way, users can extend programs contents according to memory of U-Disk. 5m USB extension cable also support for U-Disk Display. Using password：When tick it, users will need to input password to enter “hardware setting”、“firmware upgrade” or cancel password; Or else, software will regard user as administrator thus no need to input password.

Default password is “168” or “888". For Video wall updates Kindly subscribe our Channel link here.    / @megatalkcafe

P6 LED Video wall how to assemble VIDEO PART: 1 click here    • HOW TO SETUP LED VIDEO WALL | P6 LED Modul...

How To setup Mobile WiFi App for LED Screen Watch this Video    • LED Wi-Fi | LED Art App mobile phone progr...

More About How To Test Led Display module    • How To Test Led Display module | P2.5 | P3...

For LED modules to buy contact : [email protected]
