XJ968-28 Fork wheel loader from tough mining stone block handler( xiajin machinery)

Описание: XJ968-28 Fork wheel loader from tough mining stone block handler (xiajin machinery)

Please contact: (TINA): 0086-15859277818, machinery888#gmail.com (# as at)

Please contact: (TINA): 0086-15859277818, machinery888#gmail.com, 892364510#qq.com, (# as at) Skype: chinamachine2007, WeChat: xiajin007 or 892364510.

Rated power 175 kw/h
Overall dimension（L×W×H） 9593×2990×3650 mm
Max. lifting height 3450 mm
Operating weight 31000 kg
Max. Limited Load 28000 kg
Bucket capacity 2.7 m3

Turning radius 8195 mm
Wheel base 4125 mm
Tread 2300 mm
Min. Ground clearance 430 mm
Unloading angle 18° 　
Haul location height（Ground clearance of material） 300 mm

Fuel tank capacity 380 L
Hydraulic fuel tank capacity 380 L
Specification of tire Front wheel With"ADVANCE"high-load three stars 26.5 steel wire tires 　

Rear wheel With "ADVANCE"26.5streng-thening tires or "ADVANCE"high-load two stars 26.5 steel wire tires

PARKER high pressure oil pipe

High Pressure Hydraulic Hose and Fittings
We use "PARKER"-the heavy duty performers (worldwide market leader in No-Skive hose technology)
Apart from excellent high-pressure performance, the multispiral hose and fittings range offers the following advantages:
1) Specially engineered shells guarantee optimum compression and grip of the fitting on the hose No-Skive design eliminates the need to remove the hose cover before crimping;
2) Manufactured from a single piece of high-grade steel, Parker monobloc fittings eliminate potential leak paths;
3) Available with high abrasion resistant TC or ST covers, prolonging hose life;
4) Low volumetric expansion at maximum working pressure;
5) Wide fluid compatibility;
6) As the hydraulic market moves towards higher working pressures and flow volumes, multispiral hoses are playing an very important role in machine design;
7) Made according to ISO, EN and SAE standards.
Parker oil pipe import from America
