LM317 Lab Power Supply ~Down to 0 Volts!
Автор: Scott Card (TheElectronicsCADguy)
Загружено: 2022-05-14
Просмотров: 6532
Описание:
The LM317 is one of the most common 'jelly-bean' parts. With the ability to have a set or adjustable output voltage, low cost, and availability from from many manufactured make it a favorite of many. The problem, how to design it to operate below 1.25V? The quick answer is to lower the voltage reference. In this video we use Proteus to design a single (AC) source regulator. This is the basis for my low cost linear power supply.
