Teardown of MOMAX MoVe 100W Triple Ports Car Charger (2C1A)

Описание: You can buy it on MOMAX: https://www.momax.net/en-us/products/...

If you wanna buy the tester of POWER-Z, you can visit our Amazon store:
https://www.amazon.com/s?me=A31UM8SRX...

Introduction
---------------------------------------------------------------
It's been a while since we took apart a car charger last time. And today, we got a 100W car charger from MOMAX.
It's equipped with two USB-C ports and a USB-A port. The 12/24V DC from the car can be converted into 5-20V DC.
Let's go ahead and take it apart to see how it can achieve high-power output.

Bill of materials (BOM)
------------------------------------------
Solid Capacitor: Shengtong Electronics
Buck-boost Controller: Toll Microelectronic TMI5700
Buck-boost MOSFET: Allepic Semi CWR03N041AP
Buck Converter Chip: Toll Microelectronic TMI2286D
Protocol Chip (USB-C1): Toll Microelectronic IM2406
Protocol Chip (USB-C2, USB-A): Toll Microelectronic IM2403
VBUS MOSFET: Allepic Semi CWT361AP

Chapter
----------------------------------
0:00 Intro
1:19 Teardown
1:41 Analysis
4:00 Summary
