Mori Seiki SV 400 CNC Vertical Machining Center Mill MV, Fanuc, 30 HP, 12000 RPM

Описание: MORI SEIKI SV-400 CNC VERTICAL MACHINING CENTER

GENERAL SPECIFICATIONS:
TABLE SIZE 35.4" x 19.7"
MAXIMUM PALLET LOAD 2,640 LBS
SPINDLE NOSE TO PALLET TOP 6" - 26"
X AXIS TRAVEL 23.6"
Y AXIS TRAVEL 16.9"
Z AXIS TRAVEL 18.1"
RAPID TRAVERSE RATE X, Y & Z AXES 1260 IPM
CUTTING FEED RATE 0.1 - 630 IPM
SPINDLE TAPER CAT 40
SPINDLE SPEEDS 12,000 RPM
SPINDLE MOTOR 30 HP
TOOL CHANGER CAPACITY 30 STATION ATC
MAXIMUM TOOL WEIGHT 17.6 LBS
TOOL CHANGE TIME (TOOL TO TOOL) 0.9 SECONDS
TOOL CHANGE TIME (CHIP TO CHIP) 2.8 SECONDS
DIMENSIONS, APPROX. 113" x 102" x 112"
WEIGHT, APPROX. 13,700 LBS
MFG DATE 2000

EQUIPPED WITH:
MORI MSC-501 (FANUC 18i) MAPPS CONVERSATIONAL CNC CONTROL,
RS-232C PORT INTERFACE FOR DNC OPERATION,
PLUMBED & PREPPED FOR THRU-THE-TOOL COOLANT,
(2) CHIP CONVEYORS (L & R),
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING),
SPINDLE CHILLER (SPINDLE OIL COOLING SYSTEM),
COOLANT SYSTEM WITH TANK & PUMP,
FULLY ENCLOSED SPLASH GUARDING, ALL AVAILABLE MANUALS
*RIGID CASTING BOX-WAY STRUCTURE*
**30 HP HIGH-SPEED SPINDLE**

LOCATION: Midwest Machinery Inc , OUR WAREHOUSE in FRANKSVILLE, WI (NEAR MILWAUKEE, WI)

You are welcome to inspect this CNC VMC Mill prior. Feel free to email or call me for any questions you may have; including shipping quotes. CALL: 2628953462 sales at mwmachinery com
