Design and Simulation of Push Pull Converter using MATLAB | SIMULINK
Автор: Electronics Maddy
Загружено: 2020-07-12
Просмотров: 6348
Описание:
This video demonstrates the design and simulation of Push-Pull Converter / isolated DC-DC Converter using MATLAB/Simulink. Push-Pull Converter is an isolated Buck converter used in SMPS applications. Push-Pull converter employs two switches (MOSFETS) across the transformer primary winding. When S1 is ON current is drawn across the primary winding due to S1. Similarly, when S2 is ON current is drawn across the primary winding due to S2. Therefore current flows continuously irrespective of the operating cycles of switches. Whereas, in an isolated converter such as flyback converter which employs only one switch, the current is drawn only when the switch is ON. Hence push-pull converters are preferred for high power ratings and are highly efficient. The design involves a lot of assumptions and care has to be taken in assuming suitable value.
#PushPullConverterMATLAB #PushPullConvertersimulink #PushPullConvertersimulation #PushPullConverterdesign #PushPullConverter #MATLAB #SIMULINK
If you have any queries please do let me know in the comments section. If you like the video, then please like and subscribe to our channel. Thank you
