Time Correlated, Multi-Channel Analog/Digital/RF Signal Analysis Workshop
Автор: Tektronix
Загружено: 2021-04-19
Просмотров: 1102
Описание:
In this workshop, Tektronix Senior Applications engineer Alan Wolke demonstrates how to perform time correlated multi-domain signal analysis across multiple channels with the Tektronix 6 Series B Mixed Signal Oscilloscope. Being able to analyze signals across multiple domains is incredibly useful in complex systems where digital, RF, and time domain signals interact with each other; interference, glitches, spurs, drop-outs, and other errors often span across multiple domains. Products from software-defined radios to radar and EW systems all rely on the complex interplay of multi-domain signals.
0:00 Intro to the 6 Series B
1:09 Intro to Tektronix FlexChannels
3:30 Intro to Spectrum View
4:03 Spectrum View basics demo
6:27 How does Spectrum View work?
9:43 Advanced demos introduction
10:31 Frequency vs. time
13:18 Multi-domain
15:59 Multi-channel RF
18:11 Frequency mixing analysis
21:38 Advanced VSA capability
25:40 LFM pulse analysis
29:44 Wideband modulation analysis
32:25 Comparison of RF analysis tools
For more 6 Series B MSO product information: https://www.tek.com/oscilloscope/6-se...
Visit our website https://www.tek.com/ for all the Tektronix related content and solutions.
#Tektronix
