Model
Tata LPT 4825 & SIGNA 4825.T BS6
Weight
Gross Vehicle Weight : 47500 kg
Engine
Engine : Cummins ISBe 6.7L BS6
Max Power : 186 Kw @ 2300 r/min
Max Torque : 950 Nm @ 1000 – 1700 r/min
Clutch
Clutch : 430 mm Dia Push type Single Plate Dry FrictionOrganic Lining
Transmission
Transmission : TATA G1150 9F (1C) +1R Manual Synchromesh
Axle
Front Axle : TATA Heavy Duty 7T Reverse Elliot Type
Rear Axle : TATA Single Reduction RA110HD
Frame
Frame : Ladder Type, Heavy Duty Frame | (285 x 65 x 8.5)
CAB/COWL
CAB/COWL : Cowl & SIGNA
Tyres
Tyres : 295/90R20 Radial Tube Tyres
Ventilation
Ventilation : Cowl - Blower | Signa - Blower & AC
Emission Control
Emission Control : DOC + DPF + SCR + AMOX
Fuel Tank
Fuel Tank : 365L (SDL: 28ft), 300L (LDL: 30ft) Polymer with Anti Fuel Theft
Deck Length
Deck Length Option : SDL: 8534 mm | LDL: 9144 mm
Options
WB (mm) : 6800
Span (mm) : 8534 | 9144
WHEELBASE & APPLICATION
Wheelbase
Wheelbase Option : 6800 mm
Application
6800 : Cement | Flyash | Clinker | Coal | Chemical/Edible Oil | Bitumen | Market Load | Const. Agg. | POL | Agri | Iron & Steel FG | Industrial goods
SERVICE SCHEDULE & WARRANTY
ODI | Interval
Engine : 80K Km (1st @ 40K Kms)
Gear Box : 160K Km (1st @ 1.2L Kms)
Rear Axle : 160K Km (1st @ 1.2L Kms)
Hub Grease : 5L km
Warranty
Driveline Warranty : 6 Year | 6 L Km
