Switch Mode Power Supply Operation! Theory plus actual Application Part lll [tagalog]

Описание: Switched-mode power supply (SMPS) is becoming more common and, in most cases, replaces the traditional theoretical linear AC-DC power supply due to reduced power consumption, reduced heat dissipation, and reduced size and weight. Switched-mode power supplies are now available in most PCs, power amplifiers, televisions, DC motor drives, etc., and switched-mode power supplies are becoming more mature, so almost anything that requires a highly efficient power supply is using SMPS.

By definition, an SMPS is a type of power supply that uses semiconductor switching technology instead of the standard linear method to supply the required output voltage. A basic switching converter consists of a power switching phase and a control circuit. The power switching stage circuit performs a power conversion from input voltage Vin to output voltage Vout with output filtering.


🔗Other related videos:

°How TL431 works?
   • Mga Bagay na dapat mong malaman sa TL431!

°How SMPS Regulates Voltage?
   • How SMPS Regulate Output Voltage? Part ll ...

°Different Application of Diode!
   • DIFFERENT APPLICATION OF DIODE [TAGALOG] #...

°Understanding How Inductor Works
   • Ano nga ba ang Inductor? |Tagalog

Other Helpful Resources:

•Understanding of Common Mode Interference and Differential Interference https://www.cdebyte.com/news/539

•Common Mode -System Analysis[ Causes & Solution]

https://resources.system-analysis.cad...

•How to Protect Circuit from Inrush Current?
https://www.circuitbread.com/ee-faq/h...

•NTC Thermistor Working
https://www.elprocus.com/ntc-thermistor/

•Thermistor- A Resistor Type
https://eepower.com/resistor-guide/re...

•The metal oxide Varistor
https://www.elprocus.com/what-is-meta...

•Metal Oxide Varistor Working
https://www.watelectronics.com/what-i...

•Shopping Link

Fnirsi-c15 Digital Oscilloscope:
https://s.click.aliexpress.com/e/_ole...

Fnirsi Multi-Function Tester:
https://s.click.aliexpress.com/e/_oBL...

Looking for Affordable PCB Fabricator?
Check this Link:https://jlcpcb.com/?from=PCBs

•Facebook Page:
https://www.facebook.com/profile.php?...

•Instagram:
https://www.instagram.com/andrewelect...

Video Chapter:
0:00 Intro
0:28 Major Section of SMPS
2:10 Varistor as a Protection Device
2:30 What is a Varistor and How it Works?
3:45 The EMI filter
4:09 What is EMI Filter?
4:25 Actual operation of EMI filter in the Circuit
5:45 What is a Thermistor?
6:05 What is the function of Thermistor in the Circuit?
6:59 The Bridge Type Rectifier Diode
7:22 Bridge Type Rectifier Diode actual operation
8:24 The function of Main filter capacitor in SMPS
10:02 How chopper transformer Induce a Voltage?
11:21 The theory on how a transformer induced a Voltage!
12:24 The Function of PWM driver and Mosfet in SMPS
12:29 What is a PWM driver?
13:13 What is the Function of Mosfet in SMPS
13:32 Explore the Surrounding Components in PWM driver!
13:39 PWM Driver Pin 1 (Output)
13:54 PWM Driver Pin 2 (VDD) Start-up and Run-DC Circuit
15:05 PWM Driver Pin 3 (NC)
15:10 PWM Driver Pin 4 (Current Sense Pin)
15:50 PWM Driver Pin 5 (R.I) Internal osc. setting
16:25 PWM Driver Pin 6 (NC)
16:30 PWM Driver Pin 7 (Feedback)
16:58 PWM Driver Pin 8 (Hot Gnd)
17:10 How Snubber Network Function in SMPS?
18:05 The "Y" Capacitor function in SMPS
19:04 The Secondary side of SMPS
20:16 The Sampling Circuit
21:11 Error Amp Circuit
21:52 The Opto-isolator
