C490 car tow hook welding machine-industrial 3D model : machine-world.net P850

Описание: This is industrial 3D model C490 car tow hook welding machine
The tow hook is commonly used on automobiles. The tow hook automatic welding equipment consists of a welding head assembly, the welding head assembly is located in the middle of the left and right sides. directly above the flip clamp assembly; flip clamp assembly In the assembly, the first cylinder drives the rack to move forward and backward along the guide rail. The active synchronous pulley drives the same side through the synchronous belt that passes straight through the worktable. The synchronous pulley is driven, the chuck and the parallel air jaw rotate together to automatically flip the workpiece mounted on the parallel air jaw in the welding head assembly; , the second cylinder drives the welding nozzle assembly to move up and down, and the motor drives the welding nozzle The part moves left and right, the welding nozzle assembly is hinged to the top plate below the welding nozzle assembly. has good operational flexibility.
Industry used: mechanical equipment
Design software: SolidWorks 2020
File format: Sldprt Sldasm
