Basic VHF and UHF Fundamentals
Автор: Dan Vanevenhoven
Загружено: 2014-12-06
Просмотров: 405101
Описание:
Basic VHF and UHF FundamentalsDive deep into the essentials of VHF and UHF radio frequencies! In this video, we break down the entire radio spectrum from Submarine VLF to Scientific EHF, before shifting focus to the core mechanics of Very High Frequency (VHF) and Ultra High Frequency (UHF) communication.
Discover how line-of-sight propagation works, how to defeat the radio horizon, the secrets to maximizing your communication range, and the structural differences between Simplex, Duplex (Repeater), and Crossband Repeat operations.
Timestamps:
0:00 - Introduction to Radio Spectrum (VLF to EHF)
1:19 - What Makes VHF & UHF Special?
1:24 - Line of Sight Propagation & The Radio Horizon
1:54 - How Antenna Height Impacts Signal Range
2:08 - Managing Feed Line & Ground Plane Losses
2:39 - Understanding Multipath Interference & Picket Fencing
2:56 - Real-World Power & Coverage Examples (WAPL vs. WGBA)
3:18 - Simplex Operation Explained (Radio-to-Radio)
3:47 - Duplex Operation & How Repeaters Work
5:06 - Crossband Repeating: Mixing Simplex & Duplex
Key Concepts Covered:
• The Radio Horizon: Why two people standing on the ground have a line-of-sight transmission limit of roughly 25 miles due to the curvature of the earth.
• The Antenna Height Advantage: Adding just 10 feet of antenna height can effectively act like doubling your power output!
• Picket Fencing: The rapid signal fluttering caused by multipath interference as radio waves refract off sharp or solid objects.
• Duplex vs. Simplex: Simplex uses one frequency for both transmitting and receiving. Duplex splits the frequencies so you transmit to a repeater on an input frequency and listen on its output frequency.
If this video helped clear up the fundamentals of VHF and UHF, make sure to hit that like button, drop your questions below, and subscribe for more amateur radio content!
73s from N9LVS!
#HamRadio #VHF #UHF #AmateurRadio #RadioSpectrum #Repeaters #RadioPropagation #LineOfSight
