SPECIFICATIONS
ELECTRICAL SPECIFICATIONS
▪ Operating Voltage Range
Reader mode: 5 to 16 VDC from a standard controller
Controller mode: PS-x25T series intelligent power supplies
▪ Input Current
Standby: 65 mA at 12 VDC
Maximum: 110 mA at 16 VDC
▪ Tamper Optical back tamper sensor, O.C. active low, 32 mA max. sink current
OPERATIONAL SPECIFICATIONS
▪ Keypad 3x4 keys for local programming and 4- to 8-digit PIN codes entry
▪ Design Epoxy potted, fully-sealed in a rugged metal enclosure, blue backlit metal keys,
highly strong construction. Suitable for extremely harsh environments.
▪ Audio/Visual Two tri-color LED indicators, built-in buzzer
READER MODE
▪ LED Control Dry contact, N.O.
▪ Facility Code Programmable
▪ PIN Code Formats 8 selectable formats, from 1- to 8-digit length PIN codes
CONTROLLER MODE (available with PS-x25T series intelligent power supplies only)
▪ Capacity 500 users, single/dual PIN code each
▪ User Levels Normal, Secure, Master
▪ Security Modes Normal, Bypass, Secure
▪ Outputs Lock Strike output
Auxiliary output (PS-x25T series)
▪ Inputs REX (Request to Exit)
Auxiliary/door monitor with 10 programmable modes
ENVIRONMENTAL SPECIFICATIONS
▪ Operating Environment All weather, indoor and outdoor use, meets IP65
▪ Operating Temperature -35°C to 66°C (-31°F to 151°F)
▪ Operating Humidity 0 to 95% (non-condensing)
PHYSICAL SPECIFICATIONS
▪ Dimensions 120 x 76 x 21 mm (4.72 x 3 x 0.83 in.)
▪ Weight 480 g (1.05 lbs)
SYSTEM COMPONENTS
AYC-Q54B is compatible with standard access controllers in Reader mode. With
Rosslare’s PS-x25T intelligent power supply series it automatically converts into
