Learn To Fix EMC Problem Easily And In Your Lab - Troubleshooting Radiated Emissions | Min Zhang

Описание: Troubleshooting EMC problem can be done directly in your lab before going into an EMC test house. Practical example in this video - fixing Radiated Emission issue of a Flyback Power supply. Thank you very much Min Zhang.

Sign up for Min's Online EMC courses here:
Practical EMC Training for Design Engineers https://marketplace.fedevel.education...

Links:
Contact Min: https://mach1design.co.uk/contact
Possibly interested in the Min's EMC course? Just fill up this form: https://forms.gle/f22WUDRhLAmvyruQ6
PDF presentation used in the video: https://mach1design.co.uk/led-radiate...
Min's company website: https://mach1design.co.uk/
More information: https://emccompliance.co.uk/

Chapters:
00:00 What is this video about
02:27 EMC pre-compliance setup in your lab
12:14 The first steps to try after seeing EMC problems
13:15 Shorter cable and why it influences EMC results
18:44 Adding a ferrite on the cable
23:32 What causes radiation
27:18 Flyback Converter / SMPS (Switching Mode Power Supply)
29:26 Using TEM Cell for EMC troubleshooting
33:04 Benchmark test with TEM Cell
35:02 Improving input capacitors
43:20 Shielding transformer
46:24 Adding Y-capacitors, low voltage capacitors
49:21 Analyzing the power supply circuit
54:30 Finally finding and fixing the source of the EMC problem
57:59 THE BIG FIX
1:06:11 Adding shield again, adding capacitors
1:12:13 The results after the fix
1:13:09 FIXED!

------------------------------------------------------
