Overview and Key Features!

The Scarlett 2i2 is a 2 in / 2 out USB recording interface featuring two award-winning Focusrite preamps. Housed in an attractive anodised aluminium unibody chassis, the interface not only sounds fantastic but looks great too. What’s more it’s solid enough to take on the road when you travel. The Scarlett 2i2 is much more than just a pretty metal box...

25 Years of experience!
For more than 25 years, Focusrite has designed some of the most popular microphone preamps in the industry. This experience has been used to create the transparent, low-noise and low-distortion preamp found not only in the Scarlett 2i2 but also our flagship Firewire interface, the Liquid Saffire 56. Plenty of available headroom makes it suitable for moving coil, condenser and ribbon microphones regardless of the source. Phantom power is provided for mics that need it.

Plug straight in!
The front panel high quality combination input can be used to connect line and instrument level signals as well as microphones. This makes it perfect for recording the output of a synthesizer or stage piano, whilst at the flick of a switch you can cater for the output of an electric or acoustic guitar.

Keep an eye on your levels!
Unique halo indicators let you know that you’ve got a good signal level for recording. Red means that your signal is clipping, and that you should reduce the gain. The halo will momentarily turn amber as the level returns to a healthy level, at which point it will turn green.

Flexible monitoring options!
A large monitor dial provides a tactile control for the volume of your speakers, whilst a high quality headphone amp provides a clean yet loud signal to headphones connected to the front panel socket. The direct monitor switch routes audio directly from the inputs to both the headphone and speaker outputs. This allows you to monitor the incoming signal with zero-latency.


Specs:
2 in / 2 out USB audio interface
96 KHz, 24-bit conversion
2 Focusrite microphone preamplifiers
Red anodised aluminium unibody chassis
2 line/mic/instrument combination inputs – high quality XLR/¼” TRS Jack Combo
2 Line/Instrument switches
2 Gain knobs
2 Gain halo signal indicators
48V Phantom power switch
Direct monitor switch
Large monitor level dial
USB Connection LED indicator
Headphone output - ¼” TRS Jack
Headphone level knob
2 balanced monitor outputs – ¼” TRS Jack
USB 2.0 Port
Kensington Lock slot
Ableton Live Lite
Focusrite Scarlett plug-in suite

Analogue Input Performance
Mic
Frequency Response 20Hz - 20kHz +/- 0.1 dB
THD+N -100dB (minimum gain, -1dBFS input with 20Hz-20kHz filter)
Equivalent Input Noise (EIN) less than -127dB: measured at maximum gain with 150Ω termination (20Hz-20kHz filter)
Gain Range -4dB to +46dB
Max Input Level +4dBu
Line
Frequency Response 20Hz - 20kHz +/- 0.1dB
THD+N -91dB (measured at minimum gain with -1dBFS input and 20Hz-20kHz bandpass filter)
Noise -104 dBu (22 Hz/22KHz bandpass filter)
Signal to Noise Ratio more than 100dB
Gain Range -21dB to +29dB
Max Input Level +20dBu
Instrument
Frequency Response 20Hz - 20kHz +/- 0.1dB
THD+N -72dB (measured at minimum gain with -1dBFS signal and 20Hz-20kHz bandpass filter)
Noise -87dBu (22Hz/22kHz bandpass filter)
Gain Range +4dB to +46dB
Max Input Level +4dBu
Analogue Output Performance
Nominal Output Level 0dBFS = 10dBu, balanced
Frequency Response 20Hz - 20kHz +/- 0.2dB
THD+N -100dB (measured with -1dBFS input 20Hz-20kHz filter, un-weighted)
Output Impedance less than 10Ω
Power Output into 150Ω 15mW
Power Output into 50Ω
30mW

Digital Performance
Clock sources Internal clock only
A-D Dynamic Range 105dB 'A-weighted' (all inputs). Converter chipset A-D dynamic range 114dB
D-A Dynamic Range 104dB 'A-weighted' (all outputs). Converter chipset D-A dynamic range 114dB
Supported sample rates 44.1 KHz, 48 KHz, 88.2 KHz, 96 KHz
Crosstalk
Input to Input Better than 90dB
Output to Output Better than 90dB
Input to Output Better than 85dB
Input Metering
Ring LED lit Green Signal present (-24 dBFS)
Ring LED lit Red Signal overload (0dBFS), peak held for approximately 1 second
Weight and Dimensions
Height 45 mm / 1 ¾ “
Width 175 mm / 7”
Depth 100 mm / 4”
Weight 580 g / 1.3 lbs
