HSS 10 Way Strat Free Way Switch Wiring
Автор: Six String Supplies
Загружено: 2021-07-27
Просмотров: 21193
Описание:
In this video we demonstrate how to wire a Free Way 5B5-02 10 way switch for an HSS setup. The setup enables 10 switching positions and different combinations/coil selections from HSS pickups.
We cover the circuit wiring, pickup installation and where to put optional resistors to get some of the single coil combinations to see 250k rather than 500k volume pot.
To go straight to the resistors: 23:19
We are using:
Free Way 5B5-02 switch: https://sixstringsupplies.co.uk/colle...
500k/250k CTS pots
0.022uF/0.047uF capacitors
Free-Way Switch diagrams: https://www.freewayswitch.com/schemat...
Guitar wiring diagrams: https://sixstringsupplies.co.uk/pages...
