Equilibrium of Concurrent Forces Ex 6 I Roller I Engineering Mechanics

Описание: In this videos you will find Solution of following Problems on Equilibrium of Coplanar Concurrent Force Systems:
1. A roller of weight W = 1000 N rests on a smooth inclined plane. It is kept from rolling down the plane by string AC as shown in figure. Find the tension in the string and
reaction at the point of contact D.

2. A circular roller of weight 1000 N and radius 20 cm hangs by a tie rope AB = 40 cm and rests against a smooth vertical wall at C as shown in figure. Determine the tension in the rope and reaction at point C.
