Fujifilm FCR XG-1 XRAY Scanner Teardown, Laser Scanner (Part 2 of 3)

Описание: Part 2: Teardown of the laser scanner module from a Fujifilm FCR XG-1 x-ray image scanner / digitizer. Also known as Computerized Radiography (CR), it fulfills the job of scanning a x-ray exposed image plate with a laser beam and extract each pixel illumination with a photo multiplier tube setup. It can scan 72 plate per hour with a maximum resolution of 7080 X 9480 in 12 bits per pixel gray scale.

Pictures and long description: https://kaizerpowerelectronics.dk/tea...
Discussion of the teardown: https://highvoltageforum.net/index.ph...

Part 1 video:    • Fujifilm FCR XG-1 XRAY Image Scanner Teard...
Part 1: pictures and long description: https://kaizerpowerelectronics.dk/tea...
