The Truth About AMD's CPU Failures: X-Ray, Electron Microscope, & Ryzen Burns

Описание: Sponsor: Warframe https://geni.us/7eMU8 - use code DUVIRI-TAL for extra unlocks
This is our Failure Analysis report of the AMD Ryzen 7800X3D CPUs that exploded on our test benches -- some as a result of over-current, some as a result of degradation leading to failure. We worked with an external Failure Analysis Lab to evaluate the result of AMD 7800X3D CPUs getting too much voltage (VSOC especially) and likely too much current, especially in scenarios where ASUS OCP fails to do anything useful. This complements our prior Root Cause Analysis we performed in part 1, linked below, and uses a scanning electron microscope, C-mode scanning acoustic microscopy, and more to investigate a burned CPU that came out of an ASUS board.

GRAB THE GN 15-YEAR ANNIVERSARY LIMITED EDITION T-SHIRT to support our work directly! That's what has enabled us to go this failure analysis path over the years! Thank you! https://store.gamersnexus.net/product...

WATCH PART ONE:    • We Exploded the AMD Ryzen 7 7800X3D & Melt...

Like our content? Please consider becoming our Patron to support us:   / gamersnexus

RELATED PRODUCTS [Affiliate Links]

AMD R7 7800X3D on Amazon: https://geni.us/tVxgE
Fire extinguisher on Amazon: https://geni.us/OyQps
APC 1500VA UPS on Amazon: https://geni.us/mz8W
AMD R7 5800X3D on Amazon: https://geni.us/8V8doYC
Intel i9-13900K on Amazon: https://geni.us/MArn4qf
Intel i5-13600K on Amazon: https://geni.us/uWzH

TIMESTAMPS

00:00 - Failure Tests
01:57 - Root Cause & Failure Analysis
03:28 - Why We Work with a Lab
04:35 - What We Have
05:01 - External Physical Inspection
06:25 - Scanning Acoustic Microscopy
09:20 - X-Ray Analysis: 2D Scan
10:22 - 3D CT Scan
11:36 - High Magnification Microscopy
12:59 - Energy Dispersive X-Ray
14:17 - Cross-Sectioning the CPU
18:01 - CRAZY Scanning Electron Microscope Xsec
20:34 - Conclusion of Failure Cause

Correction: 06:59 Should read kV, not KHz
