VEXO X-POT Side Stream Filtration Range

Описание: What is an X-POT?
The X-POT is an award-winning patented side stream filtration unit replacing the need for separate equipment by combining the following:

Magnetic Filters: In the primary chamber all magnetic particles are removed by a minimum of four powerful rare earth magnets, all encased in easy to clean 316 stainless steel.
Cartridge & Bag Filters: The system water then passes through the stainless steel baffle plate into a secondary chamber where the fine filtration cartridge or bag captures non magnetic debris, biofilm and corrosive micro bubbles
Dosing Pots: The tundish on top of the primary chamber allows for easy dosing of the adequate water treatment additives required for the system.
Dirt & Air Separators: The automatic air vent removes air accumulated in the system without the need for manual intervention preventing problems such as corrosion and cavitation in the circulation pumps.

The X-POT Range:

X-POT Compact - Up to 4 BAR / 34,560L System Volume
X-POT 6 - Up to 7 BAR / 86,400L System Volume
X-POT XP - Up to 16 BAR / 302,400L System Volume
X-POT XXP - Up to 30 BAR / 302,400L System Volume
X-POT HFHP Up to 10 or 30 BAR / 2,592,000L System Volume

The X-POT+ Range (Skid Unit with PD-Monitor and Pump):
X-POT 6+ - Up to 10 BAR / 86,400L System Volume
X-POT XP+ - Up to 16 BAR / 302,400L System Volume

Find out more at vexoint.com/xpot
