FOX DHX 2 2016-2020 Service || Full Rebuild ||

Описание: FOX DHX 2 2016-2020 Service || Full Rebuild || #ridefoxbike #bikemaintenance #nasabiketech


New for 2016
Maintenance Info:
Service Interval Full Service 125 Hours
398-00-418 Tooling: 2016 Float X2, Bullet Tool
803-00-805 Kit: Shaft Clamps, Shocks, CTD 9mm, 3/8in, 1/2in, 5/8in
803-00-463 Kit: Fill Machine Adapter, 04-07 Epic IV, DHX Air, RC2_RC4 Shocks, Hand bleed optional
803-00-566 Kit: Bike IFP Depth Setting Tool Set
803-00-950 Seal Kit: DHX2 Damper Rebuild

Oil Info:
025-02-003 Oil: AM, FOX Suspension Fluid [32 oz.], 10 WT Red

x2 mtb shock serviced enduro pivot firebird bike #mtb suspension service mtb maintenance fox

IFP Info:
IFP Pressure 150 psi
Shock Size IFP Heights (All measurements +/- .050in)
7.875 x 2.250 1.243in/ 31.57mm
8.500 x 2.500 1.293in/ 32.84mm
8.750 x 2.750 1.343in/ 34.11mm
9.500 x 3.000 1.393in/ 35.38mm
10.500 x 3.500 1.443in/ 36.65mm

New for 2018:
New DHX2 Shaft Seal Reduces friction
New Eyelet Assy's for MY18 Increases IFP flow
New 5wt Oil 5wt. oil now used for MY18 DHX2
New inner body and piston Smaller diameter inner body and piston
New 2-Pos Lever and Valve Seat Kit available listed below. Backwards compatible for MY16-MY17.

Continuing Technologies:

2016-2017 DHX2 Continued Support
Maintenance Info:
Service Interval Full Service 125 Hours
398-00-418 Tooling: 2016 Float X2, Bullet Tool
803-00-805 Kit: Shaft Clamps, Shocks, CTD 9mm, 3/8in, 1/2in, 5/8in
803-00-463 Kit: Fill Machine Adapter, 04-07 Epic IV, DHX Air, RC2_RC4 Shocks,
Hand bleed Optional
803-00-566 Kit: Bike IFP Depth Setting Tool Set
803-00-950 Seal Kit: DHX2 Damper Rebuild
398-00-662 Service torque tool for X2 two position lever

Oil Information:
Damper 025-06-006 Oil: Suspension Fluid [250 ml. ] R3, 5WT, ISO 15
025-06-007 Oil: Suspension Fluid [1.00 Quart] R3, 5WT, ISO 15

IFP Information (All Sizes/Travels):
IFP Pressure 125 psi
IFP Height +/- 0.020in 1.343in



Source :
https://www.ridefox.com/fox17/help.ph...
https://www.ridefox.com/fox17/help.ph...
