FEA: Beam Bracket (Analysis) SolidWorks II Simulation

Описание: In this video, I am going to explain about static analysis (FEA) of Beam Bracket in Simulation module of SolidWorks. Also, I am going to explain, how to analysis stresses, deformation of component and calculate Factor of Safety of the component.

Problem Statement: Beam Bracket shown in the figure is fastened with the Steel Beam on the Ceiling of a Machine Room using 2 (M16) Bolts . The load of applied 1000 N on the inner cylindrical surface. The bracket material is Aluminum - 1060 Alloy. Find out the maximum stress and its location in the bracket and Factor of Safety of the Bracket.

We are going to learning about the following things in this Video:
-Problem Statement
-How to apply material in simulation model
-Loading Condition
-Boundary Conditions
-Applying Mesh
-How to run simulation for results
-Results discussion on Stress, Displacement & Factor of Safety
