SMG BarCraft XA NC Three in One Busbar Processing Station Training Video

Описание: Elevate your busbar processing with the SMG-3000XA NC Three In One Busbar Processing Station. Designed to enhance metal fabrication, this machine combines cutting, punching, and bending into a single, efficient workflow. It uses three separate hydraulic power packs to deliver exceptional performance.

Features

• CUT–Double column shear structure
The shearing station has a strong double column structure for stability and precision. Each cut is clean and smooth, without scrap, burrs, or collapse.

• PUNCH—a unified six-mode turnplate featuring a tooth-shaped design.
Design to enhance punch die alignment, extending their lifespan and reducing the need for frequent replacements. Utilize three precise positioning methods—coordinate axis positioning, a punch positioning pin, and a central laser pointer—to accurately locate hole centers for perfect punching.

• BEND — Controlled by a SIEMENS system
Controlled by an advanced SIEMENS system, the bending station provides high accuracy and can perform various bends like vertical, horizontal, U-shaped, Z-shaped, twisted, and embossing. Just input your data, and the machine completes your complex bending tasks with precision.

Technical Specifications:
Punching
Max Punching Force (kn): 300kn
Punching dia. range (mm): Ø 4.3 – Ø 25 mm
Max. thickness (mm): 12mm
Max. width (mm): 160mm

Shearing / Cutting
Max. shearing thickness (mm): 12mm
Max. shearing width (mm): 160mm

Vertical Bending
Max. Bending Force (KN): 300mm
Max. Thickness (MM): 12mm
Max. Width (MM): 160mm

Who is this video for?

This training video is ideal for new operators, fabrication shop technicians, and anyone looking to enhance their understanding of busbar processing and the SMG-3000XA.

Don't forget to like, comment, and subscribe for more industrial machinery training videos!

#BusbarProcessing #MetalFabrication #SMG3000XA #CNCMachine #Punching #Bending #Cutting #IndustrialMachinery #TrainingVideo #Manufacturing



Horizontal Bending
Max. Width (MM): 120×10
Max. Angle (Degree): 90°

Twist Bending
Max. Thickness (MM): 12mm
Max. Width (MM): 160mm

Outer Dimension: 1900 x 1620 x 1500mm
Power: 3 x 4.0kw
Net Weight: 1050 kg
Gross Weight: 1150 kg

CNC Precision
Bending Precision: ±1°
Repeat Bending Precision: ±0.3°

Standard Accessories:
• Punching Dies: 8 sets
Available Tooling Size:
Round hole of punching die: Φ7, Φ9, Φ11, Φ13, Φ15, Φ17, Φ19, Φ21 (mm)
Oval hole of punching die: 7×11 (mm), 9×13 (mm), 11×15 (mm), 13×18 (mm), 17×21 (mm)
Customized Punching Tooling also available
• Cutting Blade: 2 sets
• Horizontal bending dies: 2 sets
• Vertical bending dies: 2 sets
• U shape bending die: 1 set
• Oil filler: 1 set
• Inner hexagon spanner: 1 set
• Hydraulic system sealing ring: 1 set
• Foot switches: 3 sets
• Limit switches: 2 pieces
• Punching location needle: 1 piece
• Magnetic location block: 1 set
• Embossing Molds: 1 set
