Festo cylinder pneumatic filling machine 500-5000ml semi automatic cream lotion filler equipment

Описание: Model YX-LC series Festo cylinder pneumatic filling machine 1000-5000ml semi automatic cream lotion sauce filler equipment
Principal Features:
A.Pneumatic parts adopt Airtag (TaiWan) elements. (German FESTO cylinder is optional)
B.Can be operated by foot pedal or by automatic timer.
C.Bottom close positive shutoff nozzles ensure drip free operations.
D.Product suction and dispensing speed adjustment.
E.No-Tools for set-up and adjustment.
F.Sanitary tri-clamp connections.
G.Quick release nozzle and feed pipe
H.Small footprint for simple bench mounting
I.Pneumatic operation suitable for harsh environments or wash down facilities.
J.Food and pharmaceutical 316L grade stainless steel contact parts.
K.With a stainless steel product hopper
L.Conform to GMP
M.Be able to be equipped with other automatic packaging machine, such as VFFS.
Application:
They are most commonly applicable for pharmaceutics, daily chemicals, foodstuffs, cosmetics, pesticides and other industrials.
Typical application: Mineral Water, Cooking Oils, Juice, Detergent,Sauce, Salad, Butter & Margarine, Ketchup, Jams, Cream, Honey, shampoos etc.
Technical Specifications of pneumatic filling machine semi automatic:
Model YX-LC02
Filing volume:500-5000ml
Air Consumption:0.6CBM/H
Air Supply Pressure: 0.4-0.6Mpa
Operation Efficiency: 20-40bottles per min (depends on product and container size)
Filling Precision: ±1%
Size :1800*860*1200mm
Weight:
Dimension & Weight: Variable, depending on the application
