InWin IW-RS224-09 Backplane Connection
Автор: InWin Server
Загружено: 2025-07-02
Просмотров: 187
Описание:
InWin IW-RS224-09 supports latest SAS4 & PCIe Gen5 backplane connectors. We provide two types of backplanes:
Backplane Type-1: SAS4 & PCIe Gen5 2U 8-bays hybrid backplane
Backplane Type-2: SAS4 & PCIe Gen5 hybrid backplane and expander
This video will show how to connect backplane with MCIO or Slimline connectors.
00:03 Preparation
00:31 MCIO 8i to MCIO 4i cable connection
00:51 Slimline 8i to Slimline 4i cable connection
【Learn More IW-RS224-09】
https://ipc.in-win.com/rackmount-chas...
【Compatible with】
IW-RS224-09 https://ipc.in-win.com/rackmount-chas...
IW-RS112-08 https://ipc.in-win.com/rackmount-chas...
