How does a proportional solenoid valve work? | Selection guide | Tameson

Описание: In this video, Max explains how proportional solenoid valves work and how to select the right one. View our proportional solenoid valve range here ► https://tameson.com/valves/solenoid-v...
-------------------------------------
Timecodes:
00:00​ - Intro
00:16​ - How does a proportional valve work?
01:00​ - Control via PWM signal
01:35​ - Burkert 8605 and Burkert 8611
01:51​ - Selecting the right valve
02:30​ - Outro
-------------------------------------
Links in this video:
Valve sizing calculator ► https://tameson.com/valve-sizing-calc...
Housing material ► https://tameson.com/select-the-right-...
-------------------------------------
Tameson is your online specialist for fluid control. On our website, you will find very clear information and tools to directly order the right product for your application. We have over 15,000 products in stock with new product types and variants added on a continual basis. Solenoid valves, ball valves, pneumatic cylinders, hoses, fittings, etc. you name it we have it or can get it. Our engineering support team and global delivery options allow for new and existing customers (B2B & B2C) to get the right product(s) at the right cost.

VISIT OUR WEBSITE:
USA, Canada & rest of world ► https://tameson.com/
United Kingdom ► https://tameson.co.uk/
Netherlands & Belgium ► https://tameson.nl/

FOLLOW US ON SOCIAL MEDIA:
Twitter ►   / supporttameson
Facebook ►   / tamesonfluidcontrol
LinkedIn ►   / tameson

TAMESON NEWSLETTER SUBSCRIPTION
It is straight forward, no nonsense, and full of relevant information about the fluid control industry once a month. We have new product announcements, technical articles, special pricing, and much more that you'll have to subscribe to see!
English ► https://tameson.us16.list-manage.com/...
Dutch ► https://tameson.us16.list-manage.com/...

-------------------------------------------
Proportional solenoid valves are used to regulate fluid flow rate by varying the orifice size, which is controlled by the plunger position. The regulated flow rate subsequently adjusts parameters affecting a process in a system, mainly fluid level, pressure, and for example temperature. Proportional solenoid valves are especially useful in systems in which the flow rate must be controlled quickly. They are only suitable for clean media.

When power is supplied to the coil, the plunger rises and pushes against the spring force to open the valve. In contrast to a standard solenoid valve, a proportional solenoid valve can be partially open, rather than only allowing fully open or closed. This is done by varying the power supplied to the solenoid coil.

The best control method is via a PWM signal. This type of signal is used to prevent static friction to ensure higher accuracy. A PWM signal places the plunger in a very fast but weak vibration, which ensures that there is constant friction on the plunger, which increases accuracy.

PMW Control signals are preferably provided by a so-called proportional controller. The usual inputs for these controllers are 0 to 5V, 0 to 10V, 0 to 20 mA or 4 to 20 mA . Common controllers are the Burkert 8605 and 8611 controllers. The 8605 is a controller dedicated for solenoid valves and the 8611 is a more universal controller that also works with other types of valves. More about controllers in another video!
-------------------------------------------
