QCAD Floor Plan Tutorial Create a 40' x 20' House Plan from Scratch

Описание: QCAD Floor Plan Tutorial - 40' x 20' Detailed House Plan Tutorial. In this comprehensive QCAD tutorial, we go step-by-step through the process of creating a professional 40' x 20' floor plan. Whether you are a beginner or looking to sharpen your 2D CAD skills, this lesson covers everything from basic wall construction to advanced block management and architectural annotations.

🏠 What you will learn in this lesson:

Setting up and managing Layers for professional organization.
Creating wall openings and drawing detailed Door and Window symbols.
Using essential Modify tools: Move, Copy, Mirror, Rotate, and Scale.
How to create and use Blocks to speed up your workflow.
Importing external Furniture symbols (DXF).
Adding professional Dimensions and room Annotations.
Exporting your final drawing to a high-quality PDF.

📥 Download Project Assets: Download the furniture symbols DXF file used in this video for FREE here: https://hbninfotech.com/downloads/dxf...

📌 Timestamps:
Intro: 0:25
Qcad Installation: 1:26
Interface: 4:49
Important Settings, Units, Toolbars etc: 4:50
Basic Commands: 10:17
Qcad Tips & Tricks: 12:20
Drawing the 40' x 20' Walls: 14:39
Setting up Layers (Walls, Doors, Windows) 23:42
Creating Door Symbols (Arc & Line tools) 25:41
Creating Window Blocks 32:15
Importing Furniture Symbols 35:00
Adding Aligned Dimensions 39:05
Text Annotations & Room Labels 40:00
PDF Export & Print Preview: 42:18

Tools Used: QCAD (Open Source 2D CAD Software). Official Link: https://www.qcad.org/en/download

If you found this tutorial helpful, please Like the video and Subscribe for more architectural CAD tutorials!
