Conveyor crate washer
DESCRIPTION:
Ultramax Bin cleaning machine enables customers to handle the whole crate washing process efficiently and with a high continuous output of as much as 400 crates per hour. Loose burrs, grease, oils, and other contaminants are left on components following machining, forging, heat treatment, and other processes are transported & stored in Plastic bins, this should be efficiently cleaned to avoid contamination carried to the component. Our crate washer machine is the perfect solution for this type of crate washer application.
This powerful yet simple bin-cleaning machine in India constructed entirely of stainless steel will wash, rinse and dry with supervision by one person. Simply place dirty crates or bins on the conveyor of the plastic bin washing machine, the bins are moving on the Stainless steel Link conveyor and move to the Wash chamber, Rinse chamber & drying chamber then move to the unloading station. In our crate tunnel washer high-pressure spray with Vee-Jet nozzles is used to scour the surfaces of the bin's outer & inner partitions, stripping away embedded soils. These spray nozzles are properly positioned jets from the top bottom, left, and right that thoroughly clean the crates and all surfaces of the bins as it passes through the washing station. All wash and/or rinse stages of our washers have been designed as recirculating solutions with highly efficient gravity & a line-micron washable filtration system. We are one of the quality bin washing machine manufacturers in India with having good customer satisfaction record & our crates tunnel washer Saves water, labor, time, chemicals, and scratching. Our bin-cleaning machine is capable of cleaning crates, pallets, trays, and bins.
PROCESS:
The following is the process that can be done in an automatic bin cleaning machine. But in general engineering, automotive automatic bin washing machine Washing & drying is used.
1. Loading Station.
2. Pressure Prewash.
3. High-Pressure wash.
4. Rinsing.
5. Compressed air blowing.
6. Hot Air drying through a double channel blower.
7. Unloading station.
8. Washing solution temperature 50 to 60 degrees.
ACCESSORIES:
• Oil separator.
• Oil skimmer.
• Mist collector
• Glass wool insulated Tank.
• Multi-stage gravity filter to safeguard pump.
• Online Washable SS Micron filter.
• High-pressure SS Wash Pump.
• Adjustable simple guide to match different sizes of bins.
• PLC Control panel.
• VFD control for Variable output to suit requirements.
• Duplex Filter


SPECIFICATION & FEATURES:
• Customised bin-size machine design with a standard concept.
• 50 bins / Hour to 400 bins / Hour.
• Spraying pressure standard 4 to 5 bars & customized up to 20 bars.
• Constructed entirely of stainless steel.
• No Gasket sealing proven Mechanical seal design.
• Effortless opening of swing door with gas spring design for Maintenance activity.
• Less spray shadow region design.
• Digital temperature control.
• High-efficiency V jet SS Nozzle
• 3 Dimensional-designed solution spray arrangement.
• Emergency stop at both ends for easy control.
• Conveyor width and tunnel height are adjustable to match the bin size.
• High specification filters, easily accessible from outside the machine
• Our bin cleaning machine is one of the High Productivity & quality cleaning bin cleaning machines in India.
• We are one of the leading bin washing machine manufacturers in India.

APPLICATION:
These machines are used for washing & drying bins/crates used in industries like
• Automotive industries.
• Component Manufacturing industries.
• Pharmaceuticals.
• vegetable and fruit processing
• beverages, sugar, milk & poultry.
• Agriculture.
• Food processing.
• Hygiene sectors.
