How to Troubleshoot a Fuel Oil Furnace | How to Replace a Cad Eye Sensor
Автор: Everyday fixes and DIYs: How do I do that?
Загружено: 2023-01-12
Просмотров: 4022
Описание:
In this video, we troubleshoot an issue with a fuel oil furnace that keeps shutting on and off.
parts used in this video:
Cadmium-Sulfide Flame Detector w/ 60" leads
Brand: Resideo
SKU: C554A1463
Amazon: https://amzn.to/3XscGRd
Supply House: https://www.supplyhouse.com/sh/contro...
Description
–
Product Overview
Photoconductive flame sensing device for sequencing oil burner systems.
On flame failure, the light sensitive cadmium sulfide cell, in conjunction with flame sensing circuitry, causes the Protectorelay® control to shutdown the main oil burner.
Glass-to-metal hermetic seal in plug-in cell prevents deterioration by humidity, soot or oil fumes.
Replaceable CAD Cell
Features
120320 Replacement Cad Cell. 7.5 mA minimum sensitivity at 2 ft. candles; 130367 Replacement Cad Cell. 12.0 mA minimum sensitivity at 2 ft. candles.
Mounting Bracket: Type R
Electrical Connections: leadwires: NEC Class 1; Includes 2 flag 1/4 in. quick connects.
Temperature Range: 140 F
Includes:A, B, E, J and P mounting brackets and fuel line adaptor
