⚙️ Designing Helical Gear in Solidworks: A Step-by-Step Guide
Автор: Cadmake
Загружено: 2025-09-20
Просмотров: 1146
Описание:
"SolidWorks Tutorial: Designing a Helical Gear from Scratch
In this video, we'll take you through a step-by-step guide on designing a helical gear in SolidWorks. Using essential commands like:
Extruded Boss command to create the gear body
Extruded Cut command to create the gear teeth
Smart Dimension command to define precise dimensions
Circular Pattern command to replicate the gear teeth
Follow along as we walk you through each step, from creating the initial profile to finalizing the helical gear design. Perfect for SolidWorks beginners and intermediate users, this tutorial will help you master the skills needed to design complex gears and mechanical components.
Watch till the end, and let us know in the comments if you have any questions or need further clarification!"
#solidworkstutorial
#solidworks
#solidworks2024 #3dmodeling
#caddesign
#solidworkstutorialsforbeginners
Let me know if you'd like me to add anything else!
