Titan Solar Generator final

Описание: The New Titan Solar Generator is ready!
More info at: https://www.pointzeroenergy.com/titan...

Battery specs For each battery:
Battery Voltage: 29.4V (only charged to 29.2)
Battery capacity:  74ah (usable) 2000 watt hours (usable)
Maximum charge current:  40A (approximately 1000 watts)
Maximum continuous Discharge: 100A (approximately 2500 watts)
Suggested continuous Discharge (for long life):  1500 watts
Maximum surge discharge current (10 seconds or less): 300A (approximately 7700 watts )
Weight: 35lbs approximately
size:  12x18.5x4.5 in

Inverter specs:
Output Voltage: 120V AC (pure sine wave)
Continuous Power output: 3,000 Watts
Peak Power output: 6,000 watts
Inverter no load power consumption: 5-15 watts (typical 10 watts)
Size (Top portion not including the battery): 12X18.5X7.75 in
weight: 35lbs (approximate)

Solar MPPT Charge Controller:
Input Volts: 35V to 145VDC
Maximum input Amps:  30 amps per input port
Maximum charging amps:  80A (40A per port)
Charge rate: up to 2000W (using both ports, and with two or more batteries)

Other specs:
AC charging: 600 watts Per charger (up to 2 chargers max)
Car port charging: 150 watts
Number of outlets: 6-15A, and one 30A RV outlet
USB Ports: 6 smart USB, 2 USB C
12V ports:  4 - regulated at 13.8V (20A each with a maximum of 20A total)
Weight: 35/35 (estimated)
Dimensions: 18.5x12x12 (battery and power module together)
