Drawing a simple UML sequence diagram from a Java program: Object-Oriented Programming with Java
Автор: DesignCodeDebugRepeat
Загружено: 2022-10-29
Просмотров: 7849
Описание:
This series of videos is suitable for programmers with some programming or Java experience who want to learn object-oriented programming and dig deeper into some other Java features. This video uses the Proverb class that was written in the video on creating a simple class in Java. In this video we draw a Unified Modeling Language (UML) sequence diagram from a client program that uses the Proverb class, introducing basic sequence diagram principles. Let's have some fun learning to create a UML sequence diagram from Java!
Here's the video creating the Proverb class:
• Creating and documenting a simple class & ...
The code and a PDF of the sequence diagram from this video, along with the Proverb class and classes from other videos using the Proverb class, are in my github repository, available here:
https://github.com/ProfessorBurke/Jav...
If you want to earn credit for learning to code, take an online course at CCRI! These videos are part of the Advanced Java course:
https://ccri.edu/comp/
00:00 About UML Sequence diagrams
01:35 Parts of a simple sequence diagram
02:54 Creating a sequence diagram for SimpleProverbClient.java
