Chevy Cruze 1.8L Ecotec Water Pump, Belt Tensioner, and Belt Replacement

Описание: The 2014 Chevy Cruze 1.8L is back with another leak. Once I gave the car back, the water pump started leaking. In this video I pressure test the coolant system to confirm the water pump leak. We then walkthrough removal and replacement of the water pump. While I was in there, the belt tensioner and belt also needed replacement. Performed the removal and replacement of that as well. Bleeding procedure and belt diagram link listed below as well.

Part Numbers:

Water Pump - AC Delco Gold PN# 252-947
Serpentine Belt - AC Delco Gold PN# 6K609
Belt Tensioner - GM Genuine PN# 25191534

Coolant Bleed Procedure from Service Manual:

1. Close the radiator drain plug.
2. Lower the vehicle
3. Ensure vehicle is level
4. Loosen the vent screw on the radiator (Top right side of the radiator)

NOTE: Close vent screw when coolant begins to flow from the vent screw.

5. Add 50/50 DEX-COOL antifreeze to the bottom line of the bleed nozzle on the coolant surge tank. When the coolant level stabilizes, add enough coolant to reach the bottom line of the down pipe hole.
6. Start the engine. After the engine starts, verify that the coolant level reaches the bottom line of the down pipe hole.
7. Install the surge tank cap
8. Warm up the engine. Run at 2,500 RPM until the engine cooling fan turns ON.

NOTE: If the heater core has been replaced, let the engine run for 2 minutes at 2,000-2,500 RPM. This ensures complete venting of the cooling system.

9. Turn the engine OFF and allow the engine to cool down.
10. Remove the surge tank cap.
11. Check the coolant level and fill to the COLD mark if necessary.
12. Inspect the concentration of the engine coolant, using GE-26568 tester.
13. Rinse away any excess coolant from the engine and engine compartment.

Belt Diagram
https://www.ccruze.com/drive_belt_rep...
